Characteristic Impedance |
Frequency Range |
VSWR |
Insertion Loss |
Blocking DC Voltage |
Contact Resistance |
|
|---|---|---|---|---|---|---|
|
Outer Contact |
Centre Contact |
|||||
|
50Ω |
50-3700MHz |
≤1.15 (50-3000MHz) ≤1.25 (3000-3700MHz) |
≤0.25 dB |
3000V |
≤0.25/0.2mΩ (N/7/16) | ≤1.00/0.4mΩ(N/7/16） |
|
Durability |
|
|---|---|
|
Mating Cycles |
≥500 |
|
Salt Spray |
Temperature Range |
Watertightness |
RoHS |
|---|---|---|---|
|
Meet 48 Hours(5% Salt Concentration) |
-45℃～+80℃ |
IP40 |
Compliance |
|
Part |
Material |
Plating |
|---|---|---|
|
Outer Conductor |
Brass |
Tri-Alloy≥3μm |
|
Center Conductor |
Brass/Phosphor Bronze |
Ag≥3μm |
|
Insulator |
PTFE/TPX |
— |
|
Body |
POM |
— |
|
Other Metal Parts |
Brass |
Ni≥2.5μm |
