Characteristic Impedance |
Velocity |
Capacitance |
Insulation Resistance |
Insulation Voltage |
Jacket Spark Test Voltage |
|---|---|---|---|---|---|
|
50 ± 2 Ω |
0.88 |
76 pF/m |
＞5000 MΩ.km |
10000 V |
8000 V |
|
Frequency （MHz） |
Attenuation dB/100m Max |
Coupling Loss 2m, (95%) dB |
||
|---|---|---|---|---|
|
0°Forward |
90°Side |
180°Back |
||
|
900 |
4.7 |
79 |
80 |
80 |
|
1800 |
8.8 |
75 |
76 |
77 |
|
1900 |
8.9 |
70 |
71 |
72 |
|
2000 |
10.0 |
71 |
72 |
73 |
|
2200 |
11.5 |
71 |
72 |
73 |
|
2400 |
13.3 |
70 |
71 |
72 |
|
2600 |
13.9 |
68 |
69 |
70 |
|
2700 |
15.1 |
69 |
70 |
71 |
Note: Attenuation tolerance 5%; Coupling Loss tolerance ±5dB
|
Weight |
Maximum Pulling Force | Minimum bending radius | Operating Temperature Range | Min. installation temperature | |
|---|---|---|---|---|---|
|
Single Bending |
Repeated Bending | ||||
|
500kg/km |
1300N |
250 mm |
300 mm |
-40℃ to +70℃ |
PE: -40℃ LSZH: -20℃ |
|
Frequency (MHz) |
VSWR (Max) |
|---|---|
|
790~960 |
1.30 |
|
1700~1900 |
|
|
1900~2050 |
1.40 |
|
2100~2200 |
|
|
2300~2700 |
|
Inner conductor |
Copper tube |
Ø 9.0 mm |
|---|---|---|
|
Dielectric |
Cellular polyethylene |
Ø 23.2 mm |
|
Outer conductor |
Copper foil |
Ø 23.5 mm |
|
Jacket |
Black PE or Black LSZH |
Ø 27.5 mm |
|
Marking |
Brand, cable type, cable ID, meter mark |
|
