| Item | Typical value | Unit | |
|---|---|---|---|
| Viscosity, 25°C | 2400 | mPa•s | |
| Density, Liquid, 23°C | 1.08 | g•cm-3 | |
| Density, Cured, 23°C | 1.16 | g•cm-3 | |
| 95% cure dose | ≤1.0 | J•cm-2 | |
| Elongation* | 4.1 | % | |
| Tensile strength* | 24.5 | MPa | |
| Modulus, 2.5% strain* | 750 | MPa | |
*Cured film thickness 75μm, test temperature at 23±2°C, humidity at 50±5%
| Item | Color | L | a | b | |
|---|---|---|---|---|---|
| YI000 | Transparent | - | - | - | |
| YI001 | Blue | 24.1 - 49.1 | -16.3 to -16.9 | -55.2 to -27.3 | |
| YI002 | Orange | 43.5 - 67.6 | 26.2 - 51.2 | 21.3 - 52.7 | |
| YI003 | Green | 33.3 - 61.2 | -51.5 to -29.9 | 6.9 - 31.9 | |
| YI004 | Brown | 20.9 - 44.0 | -3.7 to 13.9 | -6.2 to 12.8 | |
| YI005 | Grey | 33.2 - 63.8 | -5.1 to 2.2 | -8.7 to -0.5 | |
| YI006 | White | 83.2 - 100.4 | -5.4 to 1.6 | -5.0 to 4.6 | |
| YI007 | Red | 24.4 - 52.1 | 32.9 - 56.9 | 4.8 - 24.7 | |
| YI008 | Black | 10.5 - 33.3 | -3.5 to 3.6 | -4.2 to 3.1 | |
| YI009 | Yellow | 65.1 - 87.5 | -4.2 to 20.1 | 35.2 - 81.7 | |
| YI010 | Violet | 33.5 - 65.5 | 9.2 - 25.8 | -43.8 to -17.8 | |
| YI011 | Pink | 46.3 - 84.6 | 16.9 - 42.9 | 0.1 - 15.1 | |
| YI012 | Aqua | 42.8 - 77.0 | -36.4 to -8.8 | -32.5 to -6.8 | |
| YI013 | Lime | 52.8 - 85.0 | -38.5 to -15.2 | 30.5 - 70.2 | |
| YI014 | Tan | 43.4 - 75.4 | -9.5 to 20.2 | 1.2 - 27.5 | |
| YI015 | Olive | 25.9 - 60.0 | -32.5 to 13.9 | -2.1 to 42.5 | |
| YI016 | Magenta | 24.4 - 60.1 | 10.1 - 38.2 | -14.6 to15.8 | |
LARMOR®YI series is a light curable material; protect this product from all sources of ultraviolet light, including fluorescent lighting and sunlight to prevent premature curing. It is recommended that this coating be stored in a dry place in unopened, undamaged, original containers at temperatures between 15° C and 30° C. Storage or shipment in cold conditions may result in a phase separation which is reversible and is corrected by heating for 24 hours at 50° C. If possible, the container should be gently rolled to assure uniform dissolution during this heating process.
LARMOR®YI series has a recommended shelf life of 12 months from the date of manufacture, provided that the above stated storage conditions are properly maintained.
This product may cause skin and/or eye irritation and skin sensitization. Material safety data sheet for all products also available from your Polytech sales representative. All safety and handling recommendations should be followed carefully.
LARMOR®YI series is manufactured using fine filtration techniques designed to eliminate fibre strength problems and ensure uniform product performance.
