With the rapid development of fibre-to-the-home and data centers, as pipeline resources are becoming scarce, it is urgent to increase the density of optical fibres and lay in limited space the optical cables that contain more fibre cores. By reducing the thickness of the outer cladding and coating of fibres while keeping the diameter of fibre core unchanged, YOFC is able to make optical fibres with small outer diameters.
YOFC's diameter-reduced fibre can be customized in terms of MFD, cut-off wavelength, outer diameter, and cladding diameter in accordance with customer requirements. Its cross sectional area can reach only 50% of that of conventional fibre or even less, as a result of which the density of optical cable may significantly increase. It is suitable for high-density, small OD optical cables and the optical devices with narrow internal space and small fibre bend radius.
Comparison of end-face size of diameter-reduced fibre (80/165μm fibre, 60/100μm fibre and 43/100μm fibre)
with that of standard fibre.
Technical support for diameter-reduced fibre splicing is available.
|Fibre Cut-off Wavelength (nm)||-||Customized on Demand|
|MFD (μm)||-||Customized on Demand|
|Cladding Diameter (μm）||40 - 125||Customized on Demand|
|Fibre Diameter (μm）||100 - 200||Customized on Demand|
|1310nm Attenuation (dB/km)||≤ 0.4||-|
|1550nm Attenuation (dB/km)||≤ 0.5||-|
|Zero Dispersion Wavelength (nm)||1300 - 1324||1320|
|Dispersion Slope (ps/(nm2·km))||< 0.11||0.092|
|Macrobend (dB)||-||Customized On Demand|
|Proof Test Level (Kpsi）||100||100 - 200|
|Dynamic Fatigue Parameter (nd)||> 20||22|
