Maximum resistance imbalance

2%

Insulation resistance

>5000MΩ·km

Characteristic impedance

4-100MHz 100±15Ω

101-250MHz  100±20Ω

251-500MHz  100±25Ω

Delay skew

≤ 45ns/100m

Operation Temperature

Installation Temperature: -20°C to +60°C

Operation Temperature: -40°C to +70°C

Cold bending: -20°C×4h no crack

Permissible bending radius during installation

Not less than 8 times the outer diameter of the twisted pair.

Bending radius

Static for 10 times the cable diameter, dynamic for 20 times the cable diameter.

Maximum tension

400N

Maximum conductor resistance

75fi/km (23AWG, LSZH-1)

85fi/km (24AWG, CM, PVC)

Insulating material

HDPE

Minimum insulation resistance

100MΩ/km

Dielectric strength

500Vac/1min

Package

305m/box

iCONEC-CC6AUH13IW004

Cat 6a UTP, UTP, LSZH-1, 23AWG, White, 305m/box.

iCONEC-CC6AUCM3BU004

Cat 6a UTP, UTP, CM, 23AWG, Blue, 305m/box.

iCONEC-CC6AUCR3BU004

Cat 6a UTP, UTP, CMR, 23AWG, Blue, 305m/box.

iCONEC-CC6AUVC3BU004

Cat 6a UTP, UTP, PVC, 23AWG, Blue, 305m/box.

iCONEC-CC6AUH33IW004

Cat 6a UTP, UTP, LSZH-3, 23AWG, White, 305m/box.

iCONEC-CC6AUH14IW004

Cat 6a UTP, UTP, LSZH-1, 24AWG, White, 305m/box.

iCONEC-CC6AUCM4BU004

Cat 6a UTP, UTP, CM, 24AWG, Blue, 305m/box.

iCONEC-CC6AUCR4BU004

Cat 6a UTP, UTP, CMR, 24AWG, Blue, 305m/box.

iCONEC-CC6AUVC4BU004

Cat 6a UTP, UTP, PVC, 24AWG, Blue, 305m/box.

iCONEC-CC6AUH34IW004

Cat 6a UTP, UTP, LSZH-3, 24AWG, White, 305m/box.
