Maximum resistance imbalance

2%

Insulation resistance

>5000MΩ·km

Characteristic impedance

4-250MHz                                       100±15Ω

Delay skew

≤ 45ns/100m

Operation Temperature

Installation Temperature: -20°C to +60°C

Operation Temperature: -40°C to +70°C

Cold bending: -20°C×4h no crack

Permissible bending radius during installation

Not less than 8 times the outer diameter of the twisted pair.

Bending radius

Static for 10 times the cable diameter, dynamic for 20 times the cable diameter.

Maximum tension

400N

Maximum conductor resistance

75fi/km (23AWG, LSZH-1, CM)

89fi/km (23AWG, LSZH-3, PVC)

93.8fi/km (24AWG, LSZH-1, CM)

Insulating material

HDPE

Minimum insulation resistance

100MΩ/km

Dielectric strength

500Vac/1min

Package

305m/box

iCONEC-CCC6UH13IW004

Cat 6 UTP, UTP, LSZH-1, 23AWG, White, 305m/box.

iCONEC-CCC6UCM3BU004

Cat 6 UTP, UTP, CM, 23AWG, Blue, 305m/box.

iCONEC-CCC6UCR3BU004

Cat 6 UTP, UTP, CMR, 23AWG, Blue, 305m/box.

iCONEC-CCC6UVC3BU004

Cat 6 UTP, UTP, PVC, 23AWG, Blue, 305m/box.

iCONEC-CCC6UH33IW004

Cat 6 UTP, UTP, LSZH-3, 23AWG, White, 305m/box.

iCONEC-CCC6UH14IW004

Cat 6 UTP, UTP, LSZH-1, 24AWG, White, 305m/box.

iCONEC-CCC6UCM4BU004

Cat 6 UTP, UTP, CM, 24AWG, Blue, 305m/box.

iCONEC-CCC6UCR4BU004

Cat 6 UTP, UTP, CMR, 24AWG, Blue, 305m/box.

iCONEC-CCC6UVC4BU004

Cat 6 UTP, UTP, PVC, 24AWG, Blue, 305m/box

iCONEC-CCC6UH34IW004

Cat 6 UTP, UTP, LSZH-3, 24AWG, White, 305m/box.
